Features

• Counterfeit Detection: Equipped with UV, MG, IR, and 2CIS (image) detection for superior counterfeit detection.
• Display: 4.5-inch TFT screen for a clear and user-friendly interface.
• Serial Number Recognition: Precise tracking of serial numbers for detailed reporting.
• Multi-Language Interface: Suitable for global users.
• Detection Features: Half-note, double-note, and chain-note detection.
• Currency Identification: Automatic recognition and multi-currency mixed counting.
• Denomination Sorting: Sorts banknotes based on the first detected denomination.
• Advanced Functions: Includes add, batch, reporting, and printing functionalities.
• Connectivity: USB, printer, and external display interfaces.
• Multi-Directional Processing: Banknotes can be processed in all four orientations.
• Software Updates: Easy upgrades via USB port.
• Supported Currencies: Compatible with TL, USD, EUR, GBP, CNY, RUB, CAD, and more.

Technical Specifications

• Hopper Capacity: Max. 500 notes.
• Stacker Capacity: Max. 200 notes.
• Feed System: Roller friction system.
• Counting Speed:
  • 800, 1000, 1200 notes/min.
  • 800, 1000 notes/min for MDC & SDC modes.
• Countable Note Size: 50×110 mm to 90×190 mm.
• Countable Note Thickness: 0.08 mm–0.12 mm.
• Power Supply: AC 100-240V, 50-60 Hz.
• Power Consumption: ≤ 80W.
• Dimensions: 245×235×280 mm.
• Weight:
  • Net: 6.5 kg.
  • Gross: 7.5 kg.
• Connection Ports: USB, RS-232, RJ-11.
• Operating Temperature: 15–35 ℃.
• Operating Humidity: 30–80% RH.
